Air Operated Diaphragm Pump, Viton® Diaphragm, 1/2" Hose Barb, 5 GPM Max Flow, 100 Max PSI

MAX 100 PSI

Dual Diaphragm Air Driven Transfer Pumps. Compact pumps with high flow and pressure capabilities. Applications include Chemical Transfer and Automotive Cleaning. Bag-in-the-Box Chemicals, Parts Washers. Capable of passing up to 1/8" solids.

Flow rates to 5 GPM and pressures to 100 PSI
Temperatures to 120 Deg. F
Self-priming to 15'
Patented shuttle valve eliminates stalling
Constructed of corrosion resistant materials to handle a wide variety of chemicals.

Construction:

Body is Polypropylene
Diaphragms and check valves are Santoprene®, Viton® or Kalrez
Springs are 316SS.

Specifications:

Gas inlet and outlet are 1/4"
Product inlet and outlet are 1/2" barbs.

Manufacturer:

SKU: FJG5700V

VIEW CATALOG PAGE E0051

$193.85 / EA

Qty:

i h

Specifications

Products specifications

Pump Type	Diaphragm
Body Material	Polypropylene
Inlet Size	1/2"
Outlet Size	1/2"
Max Diam. Solids	1/8"
Inlet Connection	Hose Barb
Outlet Connection	Hose Barb
Max GPM	7
Max PSI	100
Max Temp (Deg. F)	120
Self-Priming	Yes
Manufacturer Part Number	G573215D
