Picture of Falk™ Wrapflex® 10R Coupling Hubs

Falk™ Wrapflex® 10R Coupling Hubs

Wrapflex® couplings accommodate up to 7-1/4" (186mm) shafts and torque loads up to 133,000 lb.in. For simplicity and cost-effectiveness over the life of your coupling, it just doesn't get any easier than this - Wrapflex® couplings from Rexnord. Wrapflex® couplings allow for 1° angular error and 40/1000's parallel alignment error.

Complete assembly requires (2) hubs and (1) Wrapflex® element. Use with 20R-E Element shown in Related Items this page.
* Maximum HP based on 1.25 factor of safety (1.22 on 5R sizes); normally used for motor-driven centrifugal pumps, gear pumps and rotary vane pumps. Cal for safe maximum HP for other applications.

† For Piston/Plunber Pumps, Downgrade HP Ratings above by 20%.
Manufacturer: Rexnord Couplings
Falk™ Wrapflex® 10R Coupling Hubs
0Types Available
Picture of (1) Falk Wrapflex® Coupling Hub (2 Required), 1-5/8" Bore, †Max 18 HP @ 1000 RPM, *Max 25 HP @ 1750 RPM, *Max 50 HP @ 3500 RPM
(1) Falk Wrapflex® Coupling Hub (2 Required), 1-5/8" Bore, †Max 18 HP @ 1000 RPM, *Max 25 HP @ 1750 RPM, *Max 50 HP @ 3500 RPM
Wrapflex Hub, 10R, 1-5/8IN Bore & Standard Keyway
SKU: RN10R-1-5/8
$79.50
i h
Ship to

DELAY MY SHIPMENT until all in-stock items AND backordered items are available in one warehouse before shipping. (You will receive only one freight bill if you choose this option).

*

Ship my in-stock items now, ship my backordered items when they become available. (You will be billed for each shipment).

*
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Picture of (1) Falk Wrapflex® Coupling Hub (2 Required), 1-7/8" Bore, †Max 18 HP @ 1000 RPM, *Max 25 HP @ 1750 RPM, *Max 50 HP @ 3500 RPM
(1) Falk Wrapflex® Coupling Hub (2 Required), 1-7/8" Bore, †Max 18 HP @ 1000 RPM, *Max 25 HP @ 1750 RPM, *Max 50 HP @ 3500 RPM
Wrapflex Hub, 10R, 1-7/8IN Bore & Standard Keyway
SKU: RN10R-1-7/8
$78.50
i h
Ship to

DELAY MY SHIPMENT until all in-stock items AND backordered items are available in one warehouse before shipping. (You will receive only one freight bill if you choose this option).

*

Ship my in-stock items now, ship my backordered items when they become available. (You will be billed for each shipment).

*
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Picture of (1) Falk Wrapflex® Coupling Hub (2 Required), 1-3/8" Bore, †Max 18 HP @ 1000 RPM, *Max 25 HP @ 1750 RPM, *Max 50 HP @ 3500 RPM
(1) Falk Wrapflex® Coupling Hub (2 Required), 1-3/8" Bore, †Max 18 HP @ 1000 RPM, *Max 25 HP @ 1750 RPM, *Max 50 HP @ 3500 RPM
Wrapflex Hub, 10R, 1-3/8IN Bore & Standard Keyway
SKU: RN10R-1-3/8
$79.50
i h
Ship to

DELAY MY SHIPMENT until all in-stock items AND backordered items are available in one warehouse before shipping. (You will receive only one freight bill if you choose this option).

*

Ship my in-stock items now, ship my backordered items when they become available. (You will be billed for each shipment).

*
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Wrapflex Hub, 10R, 20mm
Wrapflex Hub, 10R, 20mm
SKU: RN10R-20MM
Call for pricing
Ship to

DELAY MY SHIPMENT until all in-stock items AND backordered items are available in one warehouse before shipping. (You will receive only one freight bill if you choose this option).

*

Ship my in-stock items now, ship my backordered items when they become available. (You will be billed for each shipment).

*
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Wrapflex Hub, 10R, 24mm
Wrapflex Hub, 10R, 24mm
SKU: RN10R-24MM
Call for pricing
